The Roadmate LY155-9 wheeled excavator is a medium-sized fully hydraulic tire excavator newly launched by the Roadmate wheeledator factory. The wheeled excavator weighs 14,500kg and is equipped with a 119-kilowatt high-power engine, with imported hydraulic system and special bridge box to ensure flexible switching between excavation and travel modes, and the work is stable, flexible and efficient.
The Roadmate LY155-9 wheeled excavator is a medium-sized fully hydraulic tire excavator newly launched by the Roadmate wheeledator factory. The wheeled excavator weighs 14,500kg and is equipped with a 119-kilowatt high-power engine, with imported hydraulic system and special bridge box to ensure flexible switching between excavation and travel modes, and the work is stable, flexible and efficient. The 155eled excavator can play a big role in urban work, and its large working range and flexible transfer make it highly profitable.
Environmentally friendly and efficient.
Imported hydraulic system.
Strong structure, solid material.
Stable job, strong adaptability.
Driving comfort,simple operation.
Maintenance convenient.
| Dimensions | |||
| Dimensions (length X width X height) | 7250×2495×3125 | Cab height | 3130mm |
| Track width | 1902mm | Wheelbase | 2770mm |
| Stroke length | 4300mm | Boom lenath | 2100mm |
| Scope of work | |||
| Maximum digging height | 8032mm | Maximum unioacing height | 5672mm |
| Maximum digging depth | 4623mm | Maximum vetical digging depth | 3894mm |
| Maximum digging radius | 7539mm | Maximrum suface digging radius | 7317mm |
| Minirrum tuing radius of the frort section | 2588mm | Minimum tuming radius at the rear end | 2200mm |
| Technical parameters | |||
| Bucket capacly | 0.6m²-1m² | Rotation speed | 14rpm |
| Travel speed | 10Km-31Km | Cimbing abity | 30° |
| Set pressure | 31.4 | Maximum bucket arm digging foroe | 68.6KN |
| Maximum bucket digging force | 94.1KN | Engine type | Water-cooled four-cylindler fuel-irjected wall pressure |
| Rated power | 119KW | Pump | Imported plunger pump |
| Vahe | Import multi-way valve | Working qualty | 14500kg |
| Tyre model | 825-20 | Number of tres | 8 |
| Ftank | 245L | Hydrauic tank | 260L |
